Dahua Wall Mount Bracket White/Grey PFB205W
Model No: DH-PFB205W
- Sku: DH-PFB205W
The DH-PFB205W wall mount bracket is an efficient and reliable way to mount compatible flat-panel displays. It is easy to install and adjustable, allowing for optimal viewing angles and a wide range of motion. This robust bracket is designed to hold up to 55 lbs and is sure to provide a secure and stable mount.
✓ Aluminum alloy material, cost-effective
✓ Dedicated for particular cameras, beautiful and elegant designed
|
Structure |
|
|
Material |
Aluminum alloy |
|
Dimensions |
161.6 mm × 125.6 mm × 76.0 mm (6.36" × 4.94" × 2.99") (L × W × H) |
|
Color |
White |
|
Net Weight |
0.49 kg (1.08 lb) |
|
Gross Weight |
0.56 kg (1.23 lb) |
|
Load Bearing |
2.0 kg (4.41 lb) |
|
Installation |
Wall mount |
|
Applicable Camera |
Please see "Accessory Selection" |
|
Product Dimensions |
128.0 mm × 81.0 mm × 170.0 mm (5.04" × 3.19" × 6.69") (L×W×H) |
|
Packaging Dimensions |
427.0 mm × 272.0 mm × 363.0 mm (16.81" × 10.71" × 14.29") (L × W × H) |
|
Packaging Method |
20 pcs in each carton |
|
Environment |
|
|
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Operating Humidity |
< 90% (RH) |
|
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Storage Humidity |
10%–90% (RH) |
